Quality Wedge Wire Screen Manufacturer in China

wedge wire filter elements for filtration

More Views

wedge wire filter elements for filtrationwedge wire filter elements for filtrationwedge wire filter elements for filtration

wedge wire filter elements for filtration

Category:Wedge Wire Application
Material:stainless steel304,316,316L
Properties:wedge wire screen
Application:water filtration, solid filtration, mining, industry filtration

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of wedge wire filter elements for filtration

Wedge wire filter elements are widely used in various industries, especially suitable for low maintenance applications as sieves and filters. It’s a new type filter component fabricated from the Fine Mesh Slot Opening Stainless Steel Wedge Wire Panels.

Wedge wire filter elements can be re-used repeatedly. The precise filter ratings are from 30 to 80 microns. Available in the form of tubes, panels, filter cylinders and bags and special filter elements. It is made by welding with profile wire on every connection spots.

Wedge wire filter elements have excellent filtration property by its special welding structure and the material of Stainless Steel.

Advantages of wedge wire filter elements for filtration

-- Good strength;

-- Good resistance to abrasion and corrosion;

-- High rigidity;

-- Good in filtration and fluidity;

-- Flat panel surface;

-- Long work time.

-- Easy to clean and back wash;

-- Uniform gap;

        wedge wire filter elements for filtration



Specifications of wedge wire filter elements for filtration:

Materail: stainless steel

Type: screen pipe

Usage: filteration



size

inner diameter

outer diameter

in

mm

In

mm

in

mm

2

51

2

51

25/8

67

3

76

3

76

35/8

92

4

102

4

102

45/8

117

5

127

5

127

55/8

143

6

152

6

152

65/8

168

8

203

8

203

85/8

219

10

254

10

254

103/4

273

12

305

12

305

123/4

324

14

356

131/8

333

14

356

16

406

15

381

16

406

20

508

18 3/4

476

20

508

Packaging and Transportation of wedge wire filter elements for filtration:

packing
