Details of wedge wire slot vee screen for filtration

The wedge wire slot vee screen is manufactured with V-shaped profile wire, which is spirally wound around a cage of longitudinal support rods.

Each intersecting point of these wires if fusion welded. The pitch of winding gives different spacing between two adjacent turns of wire.

This spacing gives passage for water to enter.

The entire process is completed on fully computerized machines.

Features of wedge wire slot vee screen for filtration

1) Continuous opening has greatly increased the water flow area, so offers a better contact with the aquifer.

2) V-type profile of the structure to avoid clogging and ensure smooth flow.

3) Continuous long-term effective use of the pore.

4) Trapezoidal filter pipe offers a solid structure, high porosity, and accurate poring.

5) Trapezoidal wire filter pipe is easy for washing, long service life, safe, reliable, comprehensive and low cost.

Applications of wedge wire slot vee screen for filtration

This screen is used in food processing, waste water filtration, pulp and paper as well as mineral processing applications. Wedge wire or profile screen half cylinders can be added to an auger or screw press to separate solids from liquids in food, waste water, minerals and industrial grit/chips from coolant.

wedge wire slot vee screen for filtration

Specifications of wedge wire slot vee screen for filtration:

Material: low carbon, stainless steel (304).

Slot size (mm): 0.10, 0.15, 0.2, 0.25, 0.30-3mm.

Diameter available: 1.5”, 2”, 3”, 4”, 6”, 8”, 10”, 12”, 14”.

Open area: up to 60%.

Lengths up to 6 meters.

Diameter: ranging from 25 to 2000mm.

End connection: plain beveled ends for butt welding or threaded.

Surface Profile and Support Profile

wedge wire slot vee screen for filtration

Surface Profile

W

H

Material

10S

0.75

1.425

S304,S316L Hastelloy, Monel alloy of nickel and titanium, and other stainless steel

11SL

10.75

1.8

22S

1.8

3.7

4S

0.45

1.2

50SL

3.4

7.5


Support Profile

W

H

Material

Q22

2

2.28

S304,S316L Hastelloy, Monel alloy of nickel and titanium, and other stainless

Q35

3

5

Q53

4

3

D56

4

5.6

D45

3.8

6.0

Packaging and Transportation of wedge wire slot vee screen for filtration:
