Quality Wedge Wire Screen Manufacturer in China

Wedge wire screen filter elements for filtration

More Views

Wedge wire screen filter elements for filtrationWedge wire screen filter elements for filtrationWedge wire screen filter elements for filtration

Wedge wire screen filter elements for filtration

Category:Wedge Wire Application
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Wedge wire screen filter elements for filtration

Wedge wire screen filter elements are made ofstainless steel wedge wire screen. Filter rating is from 30 to 80 microns. Wedgewire screen is welded onto rods with stainless steel wedge wire at every contactpoint. They are classified into filter sheet, filter basket and filter elements.They have such characteristics as good strength, high ridity, resistance toabrasion and corrosion, even gap, good in filtration and fluidity, easy to cleanand back wash.

Characteristics of Wedge wire screen filter elements for filtration

Easy to leak,wear and corrosion resistance.Net wire cross section is trapezoidal.

Sieve made of stainless steel wire cold rolled section,shall support the use of automation production equipment sieve welded seam screen uniformity,welding quality and stability,opening rate,long life,has high strength,stiffness and carrying capacity,can be molded into the shape of rigid screening filter.

Application of Wedge wire screen filter elements for filtration

Wedge wire screen filterelements are used in sieving of petroleum, chemical industy, pharmaceutics, foodand beverage, metallurgy and coal, also can be used in filtration of watertreatment.

We supply wedge wire screen or profile screen in flat, curved or cylindrical panels made of looped, round and/or wedge shaped woven wires for precise openings.

Wedge wire screen is supplied in stainless steel and other special steel metals and alloy metal screens, mainly used on dewatering equipment.

Wedge wire screen filter elements for filtration

Specifications of Wedge wire screen filter elements for filtration:

Wedge wire screen filter elements for filtration

Material:

Low carton, low carton galvanized steel (LCG), steel treated with plastic spraying, stainless steel (304,316etc.)

Wedge Wire (mm):

Width : 1.50 1.80 2.30 3.00 3.30 3.70

Height : 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00

Support Rod (mm):

Width : 2.30 3.00 3.30 3.70

Height : 2.70 3.60 4.70 5.60 6.30

Round : 2.50mm -- 6.0mm

Diameter ranging

from 1 inch -----45 inch.

Length:

lengths up to 6 meters.

Slot size:

0.10, 0.15, 0.20, 0.25, 0.30,....., 3.00 also achieved upon request.

Note: Other specifications can be customized according to your requirement

Wedge wire screen filter elements for filtration

Packaging and Transportation of Wedge wire screen filter elements for filtration:

transportation
