Quality Wedge Wire Screen Manufacturer in China

Supplying stainless steel wedge wire flat panel

More Views

Supplying stainless steel wedge wire flat panelSupplying stainless steel wedge wire flat panelSupplying stainless steel wedge wire flat panel

Supplying stainless steel wedge wire flat panel

Category:Wedge Wire Application
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Supplying stainless steel wedge wire flat panel

Stainless steel wedge wire flat panel is constructed using rectangular support rods or round support rods. Flat wedge wire screen panel can be designed to maximize the open area, strength and wear life to suit any application.

Flat wedge wire screen panel can be framed and or reinforced to suit a particular application. Typical framing includes standard bar or angle welded to the sides of the panel. Custom framing and reinforcing is commonly added for ease of installation and to meet loading requirements.

Flat wedge wire screen panel can be manufactured to your own size and specification.

Features of stainless steel wedge wire screen flat panel

1) Wedge wire screen style isn't easy to be locked.

2) Due to the different pressure between inside from outside,it could be very easily to clean the plugging material.

3) We are eager for long-terms cooperative parters, our factory promise the best quality to have a high filtering accuracy, high strengh and durability.

4) We have the most advanced equipments and the most professional workers, so totally could be as per customer's drawing to produce new styles.

Usages of stainless steel wedge wire screen flat panel

1) Widely used in vairous kinds of medium filtering

2) As the fitting using in the water-treating equipment ( the environment protection; the sea water transforms into the industrial water and life use water desalination treatment; running water treatment; softening treatment;

3) The petroleum industry: the petroleum product terminal filters and the chemical acid; the alkali liquid filters, the ethyl alcohol;

4) The organic solution recycling filter.

Supplying stainless steel wedge wire flat panel

Specifications of Supplying stainless steel wedge wire flat panel:

Supplying stainless steel wedge wire flat panel

Slot Size (mm): 0.025mm 0.10, 0.15, 0.2, 0.25, 0.30-3mm

Open Area: up to 60%

Width: ranging from 25 to 800mm

End Connection: plain beveled ends for butt welding or threaded

Material: Low Carbon Galvanized ( LCG ) and Stainless Steel (SS)

Slot (mm): 0.025 0.1、0.25、0.50、0.75、1.00、1.50、2.00、3.00 and so on.

Supplying stainless steel wedge wire flat panel

Packaging and Transportation of Supplying stainless steel wedge wire flat panel:



transportation
