Supplying stainless steel sieve bend screen plate for food processing

More Views

Supplying stainless steel sieve bend screen plate for food processingSupplying stainless steel sieve bend screen plate for food processingSupplying stainless steel sieve bend screen plate for food processing

Supplying stainless steel sieve bend screen plate for food processing

Category:Wedge Wire Application
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Supplying stainless steel sieve bend screen plate for food processing

Stainless steel sieve bend screen plate also known as side hill screens, parabolic screens, run down screens, gravity screens and DSM screens, can be custom designed to separate solids from liquids in various applications including food processing, pulp and paper, waste water cleanup, surface water intakes, corn wet milling, coal preparation, and gold recovery.

Sieve Bends are cross-flow screens. The profile wires are slightly tilted so that the leading edge is position higher which greatly increases the dewatering capacity.

A sieve bend consists of a concave curved profile wire screen mounted in a frame with the screen openings perpendicular to the flow. A curved screen has greater capacity than a flat wedge screen due to forces exerted as material flows against the curved surface.

Supplying stainless steel sieve bend screen plate for food processing


Features of Supplying stainless steel sieve bend screen plate for food processing

1.Compact construction, heat resistant, rust-resistant, good mechanism performance, long working life, wear-resistant
2.well-proportioned screen aperture, not prone to jam, increase quality and efficiency of refined powder.
3. Proper construction, saving time and strength during installation and replacement, i.e.
reducing time for installation, examination and maintainance, decreasing labor strength.

Application of Supplying stainless steel sieve bend screen plate for food processing

They are used in industries such as Sugar, Coal Mining & Quarrying, Mineral Processing, Cement, and Industrial & Urban Effluent Treatment etc.
Sieve bend screens are also used as a pre-filter in urban & industrial waste treatment plants to improve the performance of the clarifier by drastically reducing the load.

Supplying stainless steel sieve bend screen plate for food processing

Specifications of Supplying stainless steel sieve bend screen plate for food processing:

Material

   Galvanized low carton (LCG), Stainless steel(SS)

Wedge Wire (mm)

   Width : 1.50 1.80 2.30 3.00 3.30 3.70

   Height : 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00



Support Rod (mm)



   Width : 2.30 3.00 3.30 3.70

   Height : 2.70 3.60 4.70 5.60 6.30

   Round : 2.50mm -- 6.0mm

Slot Size

   0.02 -- 6.00mm ,also can be customized as your request.

Length

   Max 6 meters.

Width

   25mm -- 1200mm.

End connection

   Plain beveled ends, flanged or threaded couplings

Note: Other specifications can be customized according to your requirement.



Supplying stainless steel sieve bend screen plate for food processing

Packaging and Transportation of Supplying stainless steel sieve bend screen plate for food processing:

packing

transportation
