Quality Wedge Wire Screen Manufacturer in China

SS wedge wire single filter nozzle for industry filtration

More Views

SS wedge wire single filter nozzle for industry filtrationSS wedge wire single filter nozzle for industry filtrationSS wedge wire single filter nozzle for industry filtration

SS wedge wire single filter nozzle for industry filtration

Category:Wedge Wire Application
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of SS wedge wire single filter nozzle for industry filtration

SS wedge wire single filter nozzle is manufactured from stainless steel material or other alloy material. The wedge wire nozzle features non-clogging, high filtering efficiency and economical. It has a wide range of applications in water treatment applications. The different wedge wire sizes and slot sizes can suit different class filtration. Continuous slot design make it high efficiency and long service life.

Features of SS wedge wire single filter nozzle for industry filtration

Non-clogging.
High open area.
High filtering performance.
Corrosion and rust resistance.
High temperature resistance.
Economical.
Easy to install and replacement.

Applications of SS wedge wire single filter nozzle for industry filtration

Wedge wire nozzles are effective in a wide range of water treatment and other industrial applications for filtering and screening. Such as, under drain media retention elements, flow distributors in demineralizers, water softeners in pressure and gravity sand filters.
Except for filtering and screening applications, wedge wire nozzles have other applications. Just install several nozzles uniformly to be used as collectors at the bottom of the vessels.

SS wedge wire single filter nozzle for industry filtration

Specifications of SS wedge wire single filter nozzle for industry filtration:

SS wedge wire single filter nozzle for industry filtration

Single Wedge Wire Nozzle

Item

D (mm)

H (mm)

L (mm)

Slot size (mm)

Flow area (mm2)

WWNS-01

45

30

180

0.18-0.5

380-493

WWNS-02

45

40

190

0.18-0.5

551-690

WWNS-03

53

40

190

0.18-0.5

453-597

WWNS-04

53

50

200

0.18-0.5

680-710

WWNS-05

53

40

235

0.18-0.5

800-920

WWNS-06

57

40

190

0.18-0.5

560-670

WWNS-07

57

50

200

0.18-0.5

780-905

Packaging and Transportation of SS wedge wire single filter nozzle for industry filtration:

transportation
