welded wire arch screen panel for food separation

More Views

welded wire arch screen panel for food separationwelded wire arch screen panel for food separationwelded wire arch screen panel for food separation

welded wire arch screen panel for food separation

Category:Wedge Wire Application
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wegde wire screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of welded wire arch screen panel for food separation

UBO company specializes in manufacturing Static Sieve Bend Screens that are used to remove substantial amount of solids from water. Apart from this, these are used for dewatering and separation of solid materials. These static sieve bend screens can be availed from us in varied screen sizes, flow capacities and widths. In addition, these requires minimum maintenance and are offered to customers at pocket friendly prices.

Features of welded wire arch screen panel for food separation

-- No moving parts
-- Low maintenance
-- Wide range of applications
-- Self cleaning

Application of welded wire arch screen panel for food separation

Mining
Industrial Solids Separation or Recovery
Sugar Mills
Poultry or fish
Textiles
Animal Waste Processing
Meat Processing
Pulp and Paper Mills
Food Processing
Fruit and Vegetable Processing

welded wire arch screen panel for food separation

Specifications of welded wire arch screen panel for food separation:

Specification (wedge wire):

Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70

Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00

Specification (support rod):

Width(mm): 2.30 3.00 3.30 3.70

Height(mm): 2.70 3.60 4.70 5.60 6.30

Round: From 2.50mm to 6.0mm

Note: other specifications available as per request

Slot size

0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.

Material:

galvanized low carton (LCG), stainless steel (304,316 etc.)

Length

up to 6 meters.

Diameter

from 25mm to 1200mm.

End connection

Plain beveled ends, flanged or threaded couplings



welded wire arch screen panel for food separation

Packaging and Transportation of welded wire arch screen panel for food separation:

transportation
