welded wedge wire resin trap
Category: | Wedge Wire Application |
---|---|
Material: | stainless steel 302,304,304L,316,316L |
Properties: | wedge wire screen |
Application: | water filtration,liquid filtration,industry filtration |
if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.
Details of welded wedge wire resin trap
UBO offers a complete range of welded wedge wire resin trap styles to suit virtually any application. All are available in a full range of construction materials with a variety of connecting flanges and housings.
UBO provide a high percentage of open area thus minimizing pressure loss through the system. Your resin trap can be designed to suit either new or existing strainer bodies.
Features of welded wedge wire resin trap
-- Reduced costs, since wedge wire screens have a very long life.
-- Greater resistance to stresses of different pressure and temperature.
-- Maximum effective flow area & operating efficiency is maintained.
-- Costly downtime for cleaning plugged screens is minimize.
Application of welded wedge wire resin trap
-- Food & Beverage Screens
-- Mineral & Aggregate Processing
-- OEM Screen Components
-- Pulp & Paper Screens
-- Refining & Petrochemical
-- Water Process & Fluid Treatment
-- Water/oil Well
Specifications of welded wedge wire resin trap:
Material:stainless steel
Type:resin trap
Slot:0.2mm and as your request
Connection: thread or flange
Screen Size |
Inside Diameter |
Outside Diameter |
OD of Female Threaded End |
||||
in |
mm |
In |
mm |
in |
mm |
In |
mm |
2 |
51 |
2 |
51 |
25/8 |
67 |
23/4 |
70 |
3 |
76 |
3 |
76 |
35/8 |
92 |
33/4 |
95 |
4 |
102 |
4 |
102 |
45/8 |
117 |
43/4 |
121 |
5 |
127 |
5 |
127 |
55/8 |
143 |
53/4 |
146 |
6 |
152 |
6 |
152 |
65/8 |
168 |
7 |
178 |
8 |
203 |
8 |
203 |
85/8 |
219 |
91/4 |
235 |
10 |
254 |
10 |
254 |
103/4 |
273 |
113/8 |
289 |
12 |
305 |
12 |
305 |
123/4 |
324 |
133/8 |
340 |
14 |
356 |
131/8 |
333 |
14 |
356 |
_ |
_ |
16 |
406 |
15 |
381 |
16 |
406 |
_ |
_ |
20 |
508 |
18 3/4 |
476 |
20 |
508 |
_ |
_ |
PROFILE WIRE |
||||||||
WIDTH(mm) | 1.50 | 1.50 | 2.30 | 2.30 | 1.80 | 3.00 | 3.70 | 3.30 |
HEIGHT(mm) | 2.20 | 2.50 | 2.70 | 3.60 | 4.30 | 4.70 | 5.60 | 6.30 |
SUPPORT ROD |
ROUND |
|||||
WIDTH(mm) | 2.30 | 2.30 | 3.00 | 3.70 | 3.30 | Ø2.5--Ø5mm |
HEIGHT(mm) | 2.70 | 3.60 | 4.70 | 5.60 | 6.30 | ---- |
