Wedge Wire Screen Pipe for Water Well

More Views

Wedge Wire Screen Pipe for Water WellWedge Wire Screen Pipe for Water WellWedge Wire Screen Pipe for Water Well

Wedge Wire Screen Pipe for Water Well

Category:Wedge Wire Application
Material:SS 304,316,316L, Stainless steel and carbon steel
Properties:filter pipe
Application:the water-treating equipment, the environmental protection, the sea water transforms into the industrial water

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Wedge Wire Screen Pipe for Water Well

Wedge Wire Wrapped Stainless Steel Pipes are made of 316L stainless steel. The profile wire are wedge shape. The support rods are square shape which welded to the inside of the filter element. The smooth side is outside. So the mesh filter has a filtering direction from outside to inside.

Supplier wedge wire screen water well casing screen filter pipe

Usages for Wedge Wire Screen Pipe for Water Well

The wedge wire screen pipe is a kind of filtered water tubing with the perforation. it can use with the deep well pump, dive the water pump, also may use in the water-treating equipment, the environmental protection, the sea water transforms into the industrial water and life use water desalination treatment, running water treatment, water softening treatment, the petroleum industry: The petroleum product terminal filters and the chemical acid, the alkali liquid filters, the ethyl alcohol and so on the organic solution recycling filters.

Advantages for Wedge Wire Screen Pipe for Water Well

-- Good resistance to abrasion and corrosion;

-- High rigidity;

-- Good in filtration and fluidity;

-- Long work time.

-- Easy to clean and back wash;

-- Uniform gap, minimum 20 micron;

Feature for Wedge Wire Screen Pipe for Water Well

• Non-clogging surface

• Large open area

• Low pressure drop

• Hydraulic efficiency

• High flow rates

• Mechanical strength

• Abrasion-resistant

• Easy cleaning

Supplier wedge wire screen water well casing screen filter pipe

Specifications of Wedge Wire Screen Pipe for Water Well:

Supplier wedge wire screen water well casing screen filter pipe

Specification (wedge wire):
Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70
Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00
Specification (support rod):
Width(mm): 2.30 3.00 3.30 3.70
Height(mm): 2.70 3.60 4.70 5.60 6.30
Round: From 2.50mm to 6.0mm
Note: other specifications available as per request
Slot size
0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.
Material:
galvanized low carton (LCG), stainless steel (304,316 etc.)
Length
up to 6 meters.
Diameter
from 25mm to 1200mm.
End connection
Plain beveled ends, flanged or threaded couplings

Packaging and Transportation of Wedge Wire Screen Pipe for Water Well:

Package: in wood case

Delivery Time: 5-25 days
