Stainless Steel Filter slot Cylinder for Water Filters

More Views

Stainless Steel Filter slot Cylinder for Water FiltersStainless Steel Filter slot Cylinder for Water FiltersStainless Steel Filter slot Cylinder for Water Filters

Stainless Steel Filter slot Cylinder for Water Filters

Category:Wedge Wire Application
Material:SS 304,316,316L, Stainless steel and carbon steel.
Properties:Wedge Wire Pipe&Cylinder
Application: water, oil, and gas wells, and for environmental well completions

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Stainless Steel Filter slot Cylinder for Water Filters

   Stainless Steel Welded Wedge Wire Screens are made in panel or cylinder type from V shaped wedge wire, with an unique welding process, offering great strength, precision, long service life.

Stainless Steel Filter slot Cylinder for Water Filters

Application for Stainless Steel Filter slot Cylinder for Water Filters:

The screen is used throughout the world for water, oil, and gas wells, and for environmental well completions. It is the dominant screen type used in the water well industry.

Advantages for Stainless Steel Filter slot Cylinder for Water Filters:

1. Production process continuity: V-shaped profile wires creating slots which enlarge inwardly and therefore avoid clogging and minimize downtime.
2. Low maintenance costs: Separation at the screen surface which can easily cleaned by scraping or back washing.
3. Maximum process output: Precise and continuous slot openings resulting in accurate separation without loss off media.
4. Low operational costs: Large open area with an effective flow, high yield and a low pressure drop (dP)
5. Long live: Welded at each intersection creating a strong and durable screen.
6. Reduced installation costs: supporting constructions eliminating costly support media and enabling a maximum flexibility in the design of components.
7. Chemical and thermal resistant: A variety of corrosion resistant stainless steel materials and many exotic alloys suitable for high temperatures and pressures.

Stainless Steel Filter slot Cylinder for Water Filters

Specifications of Stainless Steel Filter slot Cylinder for Water Filters:

Stainless Steel Filter slot Cylinder for Water Filters

Specification (wedge wire):
Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70
Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00
Specification (support rod):
Width(mm): 2.30 3.00 3.30 3.70
Height(mm): 2.70 3.60 4.70 5.60 6.30
Round: From 2.50mm to 6.0mm
Note: other specifications available as per request
Slot size
0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.
Material:
galvanized low carton (LCG), stainless steel (304,316 etc.)
Length
up to 6 meters.
Diameter
from 25mm to 1200mm.
End connection
Plain beveled ends, flanged or threaded couplings

Packaging and Transportation of Stainless Steel Filter slot Cylinder for Water Filters:

Stainless Steel Filter slot Cylinder for Water Filters

Stainless Steel Filter slot Cylinder for Water Filters

Stainless Steel Filter slot Cylinder for Water Filters
