SS wire filter nozzle for water treatment

More Views

SS wire filter nozzle for water treatmentSS wire filter nozzle for water treatmentSS wire filter nozzle for water treatment

SS wire filter nozzle for water treatment

Category:Wedge Wire Application
Material:stainless steel 302,304,316,316L
Properties:wedge wire screen
Application:water, oil, liquid filtration, industry filtration.etc

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of SS wire filter nozzle for water treatment

SS wire filter nozzle is formed by welding wire(cross section is wedge)through a special welding technology welded on the support wire, use Special equipment for resistance welding, high welding strength, uniform gap, strong corrosion resistance, effective filter area, high penetration efficiency, simple structure, minimum aperture 25μm, arbitrarily chosen by the customer.

Features of SS wire filter nozzle for water treatment

High mechanical strength, can withstand greater pressure
Uniform aperture, form uniform filter cake, beneficial backwash regeneration
Wedge-shaped filter gap, improve backwash regeneration capacity
High pressure, high temperature, anti-aging, corrosion resistant, available for many types liquid.
Almost two-dimensional filter, without particle accumulation, can gather energy when backwash, good backwash effect.

Application of SS wire filter nozzle for water treatment

Nozzles can be used for liquid/solid or gas/solid separation, or media retention (sand, catalyst, resin).The nozzles are mounted on a support plate. The dimensions and the distribution of the nozzles on the support plate can be altered to obtain an optimized flow distribution.

SS wire filter nozzle for water treatment

Specifications of SS wire filter nozzle for water treatment:

SS wire filter nozzle for water treatment

D L L1 L2 Slot Size d Flow Area mm2
45 110-170 34 34 0.2-0.25 M24 390-493
45 110-170 44 44 0.2-0.25 M24 551-690
53 120-180 34 34 0.2-0.25 M27 453-597
53 120-180 44 44 0.2-0.25 M30 680-710
57 120-180 50 50 0.2-0.25 M32 800-1000
60 120-180 50 50 0.2-0.25 G1" 950-1188
