ASTM316HC Continuous Cylinder Screen for water treatment

More Views

ASTM316HC Continuous Cylinder Screen for water treatmentASTM316HC Continuous Cylinder Screen for water treatmentASTM316HC Continuous Cylinder Screen for water treatment

ASTM316HC Continuous Cylinder Screen for water treatment

Category:Wedge Wire Application
Material:stainless steel
Properties:Stainless Steel Pipe
Application:filters, strainers, architectural screens, water treatment underdrains, media support grids and overlays

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of ASTM316HC Continuous Cylinder Screen for water treatment

   Stainless steel wedge wire tubes is made by wrapping and welding stainless steel V-shaped profile wire cylindrically around support rods under automatic wire screen machine. Each profile wire and support rod is welded by resistance welding.

Application for ASTM316HC Continuous Cylinder Screen for water treatment:

wedge wire screen is widely used in filters, strainers, architectural screens, water treatment underdrains, media support grids and overlays, infiltration gallery screens, lauter tun screens,many other liquids, solids separation applications.

Construction for ASTM316HC Continuous Cylinder Screen for water treatment:

1. We use wedge-shaped profile wire in order to make the slot v-shaped.It can stop the impurities very well.
2. The wedge wire was welded on the support wire well-proportioned and have perfect roundness. Ensure the screen have bigger filter area and non obstructive, avoid the high concentration of impurities.
3. After work for a period of time, the filter can be back flush.It can use for many times.

Characteristic for ASTM316HC Continuous Cylinder Screen for water treatment:

1)Custom Designed and Engineered for water well drilling screen
Each project is specifically designed to ensure complete satisfaction. We provide guidance and support from project concept to completion.
(2)Longer Lasting of water well drilling screen
Johnson water well screen, whose manufacturing standards are the most stringent in the industry, are extremely durable and have high resistance to abrasion, corrosion and impact damage.
(3)Lower Maintenance of water well drilling screen .
The rugged construction and high quality of materials make possible a product that lasts longer and requires less maintenance.
(4)Less Costly of water well drilling screen
Superior operating efficiency, extended service life and reduced maintenance needs combine to reduce the true cost of long zhong long water well screens to plant operators.

ASTM316HC Continuous Cylinder Screen for water treatment

Specifications of ASTM316HC Continuous Cylinder Screen for water treatment:

ASTM316HC Continuous Cylinder Screen for water treatment

Size
(inch)
O.D
(mm)
Slot
(inch)
Collapse Strength
(Psi)
Tensile Weight
(Ton)
Wrap(thick*deep)
(mm)
Rods
(mm)
4
117
0.04
395
6
2.2*3.0
3.8mm/22
4
114.3
0.04
395
6
2.3*3.0
3.8mm/22
6
168.3
0.04
252
8
2.3*3.5
3.8mm/32
8
219.1
0.01
399
10.5
3.0*5.0
3.8mm/48
8
219.1
0.02
370
10.5
3.0*5.0
3.8mm/48
8
219.1
0.04
323
10.5
3.0*5.0
3.8mm/48
10
273.1
0.01
206
11
3.0*5.0
3.8mm/50
10
273.1
0.02
191
11
3.0*5.0
3.8mm/50
10
273.1
0.04
167
11
3.0*5.0
3.8mm/50

Packaging and Transportation of ASTM316HC Continuous Cylinder Screen for water treatment:

1.Each product is packed with bubble bag and then few bags to a wooden case (fumigation certificate)
2.We have a very trust forwarding company cooperate for long time and establish a solid partnership,of course,you can also arrange forward to take products from our factory.
