304 wedge wire well screen pipe for water pump

More Views

304 wedge wire well screen pipe for water pump304 wedge wire well screen pipe for water pump304 wedge wire well screen pipe for water pump

304 wedge wire well screen pipe for water pump

Category:Wedge Wire Application
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of 304 wedge wire well screen pipe for water pump

We supply wedge wire screen or profile screen in flat, curved or cylindrical panels made of looped, round and/or wedge shaped woven wires for precise openings.

Wedge wire screen is supplied in stainless steel and other special steel metals and alloy metal screens, mainly used on dewatering equipment.

Wedge wire screen is made with certain size of woven wire cloth as screen fabrics, then framed with stainless steel or coated carbon steel plates.

Advantages of 304 wedge wire well screen pipe for water pump

High open area
Quick filtration
Economical solution, also for refurbishing of existing lauter tuns
Accurate filter rating
Longer service life
Low maintenance costs
Possible to build-in in existing equipment(custom made)

Uses of 304 wedge wire well screen pipe for water pump

The wedge wire well screen pipe has a wide range of applications in the field of process, engineering such as sugar juice filtration, waste water treatment, crude oil and natural gas production and vessel internals solving problems of solid , liquid , solid and gas separation, filtration of oils, greases, paints, food products, water, fuels, liquid cooling agents, chemicals etc.

304 wedge wire well screen pipe for water pump

Specifications of 304 wedge wire well screen pipe for water pump:

304 wedge wire well screen pipe for water pump

No.

(mm)TYPE

OD

(mm)

ID

(mm)

Support wire Number

Filter direction

1

SRD 40

40

31

8/10

FOTI/FITO

2

SRD 45

45

36

10/12

FOTI/FITO

3

SRD 48

48

38

12

FOTI/FITO

4

SRD 60

60

51

12

FOTI/FITO

5

SRD 70

70

61

12/18

FOTI/FITO

6

SRD 85

85

76

18

FOTI/FITO

7

SRD 110

110

101

24

FOTI/FITO

8

SRD120

120

111

24

FOTI/FITO

Remarks:
1.   Make high precision wedge wire screen with different material according to user requirements.
2.   high precision wedge wire screen' should be bigger than 0.020mm slot and less that 2500mm long.

Packaging and Transportation of 304 wedge wire well screen pipe for water pump:
