Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

More Views

Stainless Steel 316 Wire Wrap V Shaped Screen PipeStainless Steel 316 Wire Wrap V Shaped Screen PipeStainless Steel 316 Wire Wrap V Shaped Screen Pipe

Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

Category:Wedge Wire Pipe&Cylinder
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen
Application:water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

Stainless steel 316 wire wrap V shaped screen pipe, also called round slot tube. It is made of stainless steel wire, which is the most popular type because of outstanding chemical stability and corrosion resistance.
As we all know, the  wire wrap V shaped screen pipe is composed of surface profiles and support profiles. The wire type of surface profile is commonly triangular wire, which is also called V-shaped wire. The support wire can be triangular wire, round wire and trapezoid wire.

Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

Advantages of Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

The Wedge Wire Screen is composed of rod strips and V shaped wires through manufacturing on specialized welding machine. The rib strips and V shaped wires will be welded by resistance welding, has enough welding strength, equally slot gap, high corrosion resistance, large filter area, good permeability, simple structure


Features of Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

Accurate filtering performance.
High efficiency.
Narrow slot openings.
Normal or high grade type for choice.
Various edge types.
Wide range of diameters for choice.
Special sizes can be customized.
Economical but high grade.
Corrosion resistance.
Rust resistance.
Long service life and durable

Application of Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

This screen pipe is applied to oil sol ution containing wax oil and asphalt or with high viscosity, it is widely applied in water treatment coarse and precise filtration of various industries, such as, power oil wells, gas wells, chemical, mining, paper making, environmental protection, metallurgy, sand—proof, decorative.

Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

Specifications of Stainless Steel 316 Wire Wrap V Shaped Screen Pipe:

Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

Specification (wedge wire):

Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70  Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00

Specification (support rod):

Width(mm): 2.30 3.00 3.30 3.70  Height(mm): 2.70 3.60 4.70 5.60 6.30 Round: From 2.50mm to 6.0mm

Note: other specifications available as per request

Slot size

0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.

Material:

galvanized low carton (LCG), stainless steel (304,316 etc.)

Length

up to 6 meters.

Diameter

from 25mm to 1200mm.

End connection

Plain beveled ends, flanged or threaded couplings

Stainless Steel 316 Wire Wrap V Shaped Screen Pipe

Packaging and Transportation of Stainless Steel 316 Wire Wrap V Shaped Screen Pipe:

transportation
