Quality Wedge Wire Screen Manufacturer in China

Wedge v wire screen panel for filtration

More Views

Wedge v wire screen panel for filtrationWedge v wire screen panel for filtrationWedge v wire screen panel for filtration

Wedge v wire screen panel for filtration

Category:Wedge Wire Screen Panel
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen panel
Application:water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Wedge v wire screen panel for filtration

The wedge v wire screen panels are manufactured to the highest standard using quality stainless steel Wedge Wire. We deliver high open area screens built for purpose. The combination of quality workmanship, superior materials, accurate slots and high open areas ensures that our panels meet the needs of the most demanding applications.

Wedge v wire screen panel for filtration

Features of Wedge v wire screen panel for filtration

Accurate slot gap, high efficiency performance, stable structure, anti-high temperature, anti-corrosive, good mechanical properties, long-lasting and durable, safe and reliable, various field can be applied.

Application of Wedge v wire screen panel for filtration

Welded V-Wire flat screens are used for wide range of applications such as sizing, classification and de-watering in mining and other industries. These are used for coal & iron ore beneficiations when fitted on the vibratory machine.

Advantages of Wedge v wire screen panel for filtration

When compared to conventional slotted pipe, wedge wire screen flat have superior open area due to their continuous slot openings. The benefits of which will :
•Reduce energy consumption and increase water flow.
•Reduce erosion of entry surfaces and increase well life.
•Allow a uniform and efficient well development.
•Reduce significantly potential pump damage and subsequent maintenance costs.

Specifications of Wedge v wire screen panel for filtration:

wedge v wire screen panel

Thickness: as per customer's requirement
Length: max:6m
Width: as per customer's requirement
profile wire: 1.5*2 2*3 (mm)
support rod: 2*3 3*5 4*6 (mm)
slot gauge: min 0.02 (mm)





grad

back width (mm)

aperture width (mm)

higher

2

0.5

medium

2.0-2.5

0.5-3

lower

2.0-2.5

> 3




Packaging and Transportation of Wedge v wire screen panel for filtration:

transportation
