Stainless steel sieving mesh
Category: | Wedge Wire Screen Panel |
---|---|
Material: | stainless steel304,316,316L |
Properties: | wedge wire screen |
Application: | liquid filter,water filtration,industry filtration |
if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.
Details of Stainless steel sieving mesh
Stainless steel sieving mesh is made of stainless steel wire.It is widely used in screening and seperation in mine, coal, grain, medicine, ceranic, glass, food, scientific research and other fields.
Materials: AISI 201, 202, 302, 304, 304L, 3016, 410, 430 stainless steel wire.
Features of Stainless steel sieving mesh
* High filtering capability at high pressure.
* Excellent anti-corrosion.
* Low pressure loss.
* Constant mesh opening.
* Good dimensional stability.
* High open surface area.
Applications of Stainless steel sieving mesh
to sieve and filter in the acid and alkali environment. Stainless steel sieving mesh is used as sieve mesh in petroleum industry, as filter-mesh in chemical industry, as screening and seperation in mine, also used in galvanized industry.
Specifications of Stainless steel sieving mesh:
Mesh/Inch |
Wire Diameter(mm) |
Slot(mm) |
Width(m) |
20*20 |
0.5 |
0.77 |
1.5--4 |
40*40 |
0.27 |
0.365 |
1.5--4 |
60*60 |
0.21 |
0.213 |
1.5--4 |
70*70 |
0.18 |
0.183 |
1.5--4 |
80*80 |
0.15 |
0.167 |
1.5--4 |
90*90 |
0.14 |
0.142 |
1.5--4 |
100*100 |
0.13 |
0.124 |
1.5--2 |
120*120 |
0.08 |
0.131 |
1.5--2 |
140*140 |
0.07 |
0.111 |
1.5--2 |
150*150 |
0.063 |
0.106 |
1.5--2 |
160*160 |
0.063 |
0.015 |
1.2--1.6 |
200*200 |
0.056 |
0.071 |
1.2--1.6 |
250*250 |
0.04 |
0.061 |
1.2--1.6 |
300*300 |
0.035 |
0.054 |
1.2--1.6 |
325*325 |
0.035 |
0.051 |
1.2--1.6 |
350*350 |
0.035 |
0.042 |
1--1.2 |
400*400 |
0.03 |
0.0385 |
1--1.2 |
