Quality Wedge Wire Screen Manufacturer in China

Stainless Steel Wedge Wire Screen

More Views

Stainless Steel Wedge Wire ScreenStainless Steel Wedge Wire ScreenStainless Steel Wedge Wire Screen

Stainless Steel Wedge Wire Screen

Category:Wedge Wire Screen Panel
Material:1Cr18Ni9Ti, 304, 316L, 904L, Hastelloy HC, B, C
Properties:sieve and filtering screen
Application:he features of the Wedge Wire screen make it an attractive solution for separating solids from liquids, retaining media, filtering, sizing, dewaterin

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Stainless Steel Wedge Wire Screen

About the Stainless Steel Wedge Wire Screen

The all-welded stainless steel construction produces high strength and extended service life suitable for many screening applications in numerous industries.Look at the bellow picture, you can find the adbantage of the wedge wire screen by yourself.all-welded stainless steel construction produces high strength and extended service life suitable for many screening applications in numerous industries

The high open area of the Wedge Wire screen provides excellent capacity. Wedge Wire screen offers continuous slot openings that widen inwardly so that particles tend to pass through the screen.

Specifications of Stainless Steel Wedge Wire Screen:

The Specification of the Stainless Steel Wedge Wire Screen

SLOT
(INCH)

LENGTH
(m)

WIDTH
(m)

COLLAPSE STERENG
(PSI)

TENSILE WEIGHT
(TON)

WRAP (thick*deep)
(mm)

RODS
(mm)

0.040

1-6

0.5-2

395

6

2.2*3.0

3.8mm/22

0.040

1-6

0.5-2

395

6

2.3*3.0

3.8mm/22

0.040

1-6

0.5-2

252

8

2.3*3.5

3.8mm/32

0.010

1-6

0.5-2

399

10.5

3.0*5.0

3.8mm/48

0.020

1-6

0.5-2

370

10.5

3.0*5.0

3.8mm/48

0.040

1-6

0.5-2

323

10.5

3.0*5.0

3.8mm/48

0.010

1-6

0.5-2

206

11

3.0*5.0

3.8mm/50

0.020

1-6

0.5-2

191

11

3.0*5.0

3.8mm/50

0.040

1-6

0.5-2

167

11

3.0*5.0

3.8mm/50

Packaging and Transportation of Stainless Steel Wedge Wire Screen:

Stainless Steel Wedge Wire Screen Production And Sales
