Softening water treatment equipment nozzle filter

    Stainless steel sand filter nozzle with thread coupling can be fixed on the filtering equipment for the filteration of water petrol resin and other medium. Also it can be used in the water treatment, water softening, conversion of sea water into fresh water, the filter of food chemistry.
     Small systems may be built moduarly from off-the-shelf components requiring minimal customization.

Uses for Softening water treatment equipment nozzle filter:

Stainless Steel wedge wire water treatment filter nozzle with thread coupling can be fixed on the filtering equipment for the filteration of water petrol resin and other medium. Also it can be used in the water treatment, water softhening, conversion of sea water into fresh water, the filter of food chemistry.

Features for Softening water treatment equipment nozzle filter:

Reduced costs, since wedge wire screens have a very long life.
Greater resistance to stresses of different pressure and temperature.
Maximum effective flow area & operating efficiency is maintained
Costly downtime for cleaning plugged screens is minimize.

Technology for Softening water treatment equipment nozzle filter:

Manfre introduce advanced korea technology , the construction method used is the latest, ultra clean TiG and plasma welding system. This method of construction guarantees cartridge integrity, eliminating the risk of bypass and the presence of extractables derived from any bonding agents

Raw material : stainless steel 304,304L,316,316L,Hastelloy alloy
Outer diameter: min 30mm.
Wedge wire screen length: 30-100mm
Screen slot :0.02-3mm
Screw thread: Male/Female
Flow capacity of one pieces of filter nozzle could handle 3 m3/hour. Up to this flow capacity, almost no pressure loss happened. But to handle higher flow capacity, the pressure loss of each nozzle will be increasing accordingly. This fillter nozzle type is the cheapest sellection for filter media retention.
