SS Wedge wire cylinder screen for groundwater

More Views

SS Wedge wire cylinder screen for groundwaterSS Wedge wire cylinder screen for groundwaterSS Wedge wire cylinder screen for groundwater

SS Wedge wire cylinder screen for groundwater

Category:Wedge Wire Application
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:Stainless Steel Pipe
Application:oil , gas , chemical , food or beverage , mining , waste water management or coal separation

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of SS Wedge wire cylinder screen for groundwater

    The V-shaped wire can be made in different height and width to address various strength application, meanwhile, the spacing of individual slots can be varied during fabrication if geologic conditions require these variations in a screen's construction

SS Wedge wire cylinder screen for groundwater

Application for SS Wedge wire cylinder screen for groundwater:

Wedge wire screen have a lot of applications like using in oil , gas , chemical , food or beverage , mining , waste water management or coal separation .

Advantages for SS Wedge wire cylinder screen for groundwater:

1. This type screen can be successfully applied for gravel packing and sand prevention. It enables the oil well to offer large output. And this product is not limited to the length of well section, bottom hole temperature or pressure.
2. The utilization of trapezoid wrapping wire contributes to the formation of V-shaped openings between the seams. This design pattern makes the water to be filtered smoothly, thus improving the efficiency.
3. The wrapping wire is connected to all the supporting wires by welding. It can be used for a long time. In addition, both dense and uniform seams will be formed after this trapezoid wrapping wire has been wrapped onto the circumferentially arranged supporting wires. Those seams offer a large flow area while ensuring the excellent anti-blocking performance. Also, they will effectively help avoid sediment accumulation. Consequently, high production efficiency of the water well can be significantly improved, and the lifespan can be prolonged as well.

Working Principle for SS Wedge wire cylinder screen for groundwater:

Inside the well, the all-welded wedge wire water screen is placed into the sand stratum. Then the gravel slurry together with the oil will be pumped into the space between the screen pipe and well. Through the multistage filtering, sand and gravel will be removed. Simultaneously, oil will get into the pipe from the holes, and then it will be continuously lifted to the ground. The sand will be controlled to turn back to the sand stratum, thus ensuring the normal production of the well. Moreover, the screen has no damage to the oil layer.

SS Wedge wire cylinder screen for groundwater

Specifications of SS Wedge wire cylinder screen for groundwater:

SS Wedge wire cylinder screen for groundwater

Screen Size
ID
OD
Female thread dismeter
in
mm
in
mm
in
mm
in
mm
2
51
2
51
25/8
67
23/4
70
3
76
3
76
35/8
92
33/4
95
4
102
4
102
45/8
117
43/4
121
5
127
5
127
55/8
143
53/4
146
6
152
6
152
65/8
168
7
178
8
203
8
203
85/8
219
91/4
235
10
254
10
254
103/4
273
113/8
289
12
305
12
305
123/4
324
133/8
340
14
356
13 1/8
333
14
356
-
-
16
406
15
381
16
406
-
-
20
508
18 3/5
476
20
508
-
-

SS Wedge wire cylinder screen for groundwater

Packaging and Transportation of SS Wedge wire cylinder screen for groundwater:

SS Wedge wire cylinder screen for groundwater



SS Wedge wire cylinder screen for groundwater
