Paper Pulp Wedge Wire Pressure Screen Basket

More Views

Paper Pulp Wedge Wire Pressure Screen BasketPaper Pulp Wedge Wire Pressure Screen BasketPaper Pulp Wedge Wire Pressure Screen Basket

Paper Pulp Wedge Wire Pressure Screen Basket

Category:Wedge Wire Application
Material:Stainless steel 302,304,304L,316,316L
Properties:Wedge Wire Pipe
Application:the water-treating equipment, the environmental protection, the sea water transforms into the industrial water and life use water desalination treatme

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Paper Pulp Wedge Wire Pressure Screen Basket

Paper pulp wedge wire pressure screen basket is made by wrapping and welding stainless steel V-shaped profile wire cylindrically around support rods under automatic wire screen machine. Each profile wire and support rod is welded by resistance welding,easily fit for pulp and paper industries for water clarification, cleaning, dewatering, pulp screening and fractionation, and other liquid/solid separation etc.

Usages for Paper Pulp Wedge Wire Pressure Screen Basket:

The wedge wire screen or strainer is a kind of filtered water tubing with the perforation. It can use with the deep well pump, dive the water pump, also may use in the water-treating equipment, the environmental protection, the sea water transforms into the industrial water and life use water desalination treatment, running water treatment, water softening treatment, also used in the petroleum industry as fittings for the petroleum product terminal filters and the chemical acid, the alkali liquid filters, the ethyl alcohol and the organic solution recycling filters

Feature for Paper Pulp Wedge Wire Pressure Screen Basket:

Reducing the total cost of screening

We have thoroughly analyzed the costs of screening for a variety of furnishes and how these costs relate to one another.We have the experience and the products to attack the major cost factors helping you reduce the total cost of screening without sacrificing reliability or performance.

Reducing energy

Screen energy consumption is primarily a function of rotor speed and design. Optimization Sinostar wire shape with the existing rotor can significantly reduce the screen Thickening Factor (TF). A lower TF will result in better screen runnability.Often the existing rotor speed can then be reduced, saving energy without diminishing screening efficiency or capacity.

Improving capacity

Reducing wire width increases the open area of the screen cylinder without reducing slot size. The result is a screen with significantly higher capacity and no loss in efficiency. We have the largest selection of narrow wires available.

Increasing efficiency

Both the wire width and profile shape can be optimized to improve efficiency,based upon the contaminant that is targeted for removal. The screen cylinder's open area determines the passing velocity, which influences the removal of deformable debris(stickies). Smaller debris is more effectively screened out by utilizing smaller slots.

Advantage for Paper Pulp Wedge Wire Pressure Screen Basket:

A good product starts from bit by bit. Stress on the particulars and make an industrial product as an artware,this is Sinostar's delighted pursuance.We give you a good product in a shortest possible time! Wherever your are, Sinostar's products can be sent to you to any part of the world quickly and the customer can be assured. Screen basket of Sinostar guarantees progressive lowering production cost,elevation of productivity improvement of quality for your company.

Paper pulp wedge wire pressure screen basket

Specifications of Paper Pulp Wedge Wire Pressure Screen Basket:

Paper pulp wedge wire pressure screen basket

Paper pulp wedge wire pressure screen basket

Specification (wedge wire):

Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70  Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00

Specification (support rod):

Width(mm): 2.30 3.00 3.30 3.70  Height(mm): 2.70 3.60 4.70 5.60 6.30 Round: From 2.50mm to 6.0mm

Note: other specifications available as per request

Slot Size

0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.

Material:

galvanized low carton (LCG), stainless steel (304,316 etc.)

Length

up to 6 meters.

Diameter

from 25mm to 1200mm.

End Connection

Plain beveled ends, flanged or threaded couplings

Packaging and Transportation of Paper Pulp Wedge Wire Pressure Screen Basket:

Package: in wood case

Delivery Time:5-25 days
