stainless welded wedge wire filter screen pipe

More Views

stainless welded wedge wire filter screen pipestainless welded wedge wire filter screen pipestainless welded wedge wire filter screen pipe

stainless welded wedge wire filter screen pipe

Category:Wedge Wire Pipe&Cylinder
Material:SS 304,316,316L, Stainless steel and carbon steel.
Properties:wedge wire screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of stainless welded wedge wire filter screen pipe

     screen pipes consist of V-shape profile wire and the longitudinal support rods. each intersecting point of these wires is fusion welded. So Wedge Wire screen pipe has sturdy constriction and good mechanical property. The V-shape section plane can avoid blockage, and make sure of the unimpeded water. The continuous slot have more open area, and it can reduce the speed of the water entering to avoid the sand entering the screen under the great pressure, so Wedge Wire screen pipe can filter sand better. Meanwhile ,the slot size can be changed according to the real condition of the customer requirements

Use for stainless welded wedge wire filter screen pipe:

1.Chemical industry
2.Oil field, gas field
3.Mining
4.Textile, dyeing, paper-making industry
5.Municipal engineering
6.Nonferrous metal
7.Agriculture
8.Sea water transportation
9.Thermal engineering
10.Buried drainage pipe, cable dredge pipe

Characteristic for stainless welded wedge wire filter screen pipe:

1.It has higher strength, stiffness, impact resistance than plastic pipe.
2.Corrosion resistance on both surfaces, it has same corrosion resistance with plastic pipe.
3.High work temperature, low thermal conductivity, heat insulation for outer wall is not required when it is used in winter, and no moisture condensation when it is used in summer.
4.Smooth and neat inner wall, no scaling, head loss is 30% lower than steel pipe.
5.Pipe connection adopts electric melting connection which is the mature technology, The electric melting joint has strong axial tension resistance. The pipe fittings have many specifications.
6.Light weight, easy transportation and construction. Overall reliability for pipes is high.
7.Low cost, health and non-toxic, it is the best substitute for galvanized pipe.

Technical requirements for stainless welded wedge wire filter screen pipe:

The color is generally black. Also can be decided according to customer negotiation.
The inner and outer surface of the tube should be glossy and smooth. Tiny pits and bumps are allowable. Air bubble, breach, decomposition color line and obvious wound are not allowable. The both ends of the tube should be cut flat.

stainless welded wedge wire filter screen pipe

Specifications of stainless welded wedge wire filter screen pipe:

stainless welded wedge wire filter screen pipe

Screen Size
ID
OD
Female thread dismeter
in
mm
in
mm
in
mm
in
mm
2
51
2
51
25/8
67
23/4
70
3
76
3
76
35/8
92
33/4
95
4
102
4
102
45/8
117
43/4
121
5
127
5
127
55/8
143
53/4
146
6
152
6
152
65/8
168
7
178
8
203
8
203
85/8
219
91/4
235
10
254
10
254
103/4
273
113/8
289
12
305
12
305
123/4
324
133/8
340
14
356
13 1/8
333
14
356
-
-
16
406
15
381
16
406
-
-
20
508
18 3/5
476
20
508
-
-



Profile Wire








Width(mm)
1.5
1.5
2.3
2.3
1.8
3.0
3.7
3.3
Height(mm)
2.2
2.5
2.7
3.6
4.3
4.7
5.6
6.3



Support Rod





Round
Width(mm)
2.3
2.3
3.0
3.7
3.3
Ø2.5~Ø5mm
Height(mm)
2.7
3.6
4.7
5.6
6.3


Packaging and Transportation of stainless welded wedge wire filter screen pipe:

stainless welded wedge wire filter screen pipe
