Quality Wedge Wire Screen Manufacturer in China

high quality wedge wire stainless steel sieve bend screen factory

More Views

high quality wedge wire stainless steel sieve bend screen factoryhigh quality wedge wire stainless steel sieve bend screen factoryhigh quality wedge wire stainless steel sieve bend screen factory

high quality wedge wire stainless steel sieve bend screen factory

Category:Sieve Bend Screen
Material:SS 304,316,316L, Stainless steel and carbon steel.
Properties:wedge wire screen
Application:industries such as Sugar, Coal Mining & Quarrying, Mineral Processing, Cement, and Industrial & Urban Effluent Treatment

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of high quality wedge wire stainless steel sieve bend screen factory

    Wedge wire filter are welded structures with the support profiles being rods in the axial direction of the tube and surface profiles spirally wound around the support profiles.
   Our wedge wire filter are manufactured directly on a machine. They have the unique advantage of very accurate, narrow slot openings and perfect roundness all in one.

high quality wedge wire stainless steel sieve bend screen factory

Application fort high quality wedge wire stainless steel sieve bend screen factory:

They are used in industries such as Sugar, Coal Mining & Quarrying, Mineral Processing, Cement, and Industrial & Urban Effluent Treatment etc. Sieve bend screens are also used as a pre-filter in urban & industrial waste treatment plants to improve the performance of the clarifier by dramatically reducing the load. Widely used for fiber removal in Starch industry.

Features for high quality wedge wire stainless steel sieve bend screen factory:

Low Headroom - only 1.1 metres (44") tall for the 900 mm arc length unit.
Energy Efficient - operates with no moving parts and with no energy input.
Space Efficient - treats up to 122 litres per second per square metre of floor space.
Quiet Operation - no moving parts means no mechanical or electrical vibrations.
Accurate Sizing - can be used for sizing solid particles down to 0.2 mm (0.008").
Low Maintenance - the profile wire screen resists clogging by near-size particles, and the all-stainless steel construction ensures a long, corrosion-free installation.
Easy Screen Replacement - a typical screen can be replaced in 10 minutes with no tools.

Characteristics for high quality wedge wire stainless steel sieve bend screen factory:

The benefit of wedge wire screen is more open area, have very precise openings ,maximum design flexibility, stronger and more durable, economical ,easier installation and long-term operating etc.

Specifications of high quality wedge wire stainless steel sieve bend screen factory:

high quality wedge wire stainless steel sieve bend screen factory

Basepipe OD (in)
Perforations per foot
Basepipe Hole Size (in)
Open Area of Basepipe Holes (in2/ft)
Wrap Wire Size Keystone (in)
Rib Wire Size Round (in)
Maximum OD (in)
1.05
54
0.312
4.14
0.09*0.09
0.125
1.489
1.315
66
0.312
5.06
0.09*0.09
0.125
1.726
1.66
78
0.312
5.98
0.09*0.09
0.125
2.126
1.90
42
0.375
4.63
0.09*0.09
0.125
2.387
2.063
42
0.375
4.63
0.09*0.09
0.125
2.55
2.375
54
0.375
5.96
0.09*0.09
0.125
2.86
2.875
66
0.375
7.28
0.09*0.09
0.125
3.362
3.25
78
0.375
8.61
0.09*0.09
0.125
3.737
3.50
78
0.375
8.61
0.09*0.09
0.125
3.987
4.00
90
0.375
9.94
0.09*0.09
0.125
4.487
4.50
102
0.375
11.26
0.09*0.09
0.125
5.001
5.00
114
0.375
12.59
0.09*0.09
0.125
5.506

Packaging and Transportation of high quality wedge wire stainless steel sieve bend screen factory:

high quality wedge wire stainless steel sieve bend screen factory
