Screen panel

The screen panels can be manufactured with a variety of rectangular or round support rods. The wire width and relief angle is determined by weight per square foot and efficiency requirements. This screen decking magnifies vibration with drum-tight tension and withstands the violent vibrating action. These industrial profile screens are also used in fluid bed dryers, coolers and much more.

Ourscreen panels are all custom made and can be designed and built to fit any screening equipment in any specified width and length. Need a stainless steel flat panel screen on an extra-large scale? No problem. Plus, size, shape and spacing of profile wire are engineered to meet your special job requirements. Individual wire on the working surface of each wedge wire flat panel screen can be manufactured at a tilt to better serve your need

Feature of Screen panel

welded wedge wire screen
High mechanical load capacity
No form closure connection that would allow vibration of the profiled bars
Automated welding process for high-precision manufacturing
Perfectly adjusted screen basket profiles
Available for all screens
Surface finishing as required

Usages of Screen panel

Applications for wedge wire screen panels include cross flow sieves, vibrating screen decking,
mineral processing, surface water intake screens, fish diversion screen panels, hatchery
screens, food processing, and flooring for malt kiln, germination, and grain drying.

Materials: stainless steel 304,316L, low carbon galvanized or as per your request.

Surface treatment: polishing, chroming

Product structure: wedge wire screen panel

Wire diameter:  1.5x2m, 2x3mm

Length: 0.5meters or as per your request

Width:as your request

Slot size:  1mm also designed as customers request.

Application  water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

Surface treatment: polishing, chroming

Product structure: wedge wire screen, pipe , cap.screen panel
