stainless steel side hill screen for filtration

More Views

stainless steel side hill screen for filtrationstainless steel side hill screen for filtrationstainless steel side hill screen for filtration

stainless steel side hill screen for filtration

Category:Wedge Wire Application
Material:stainless steel 302,304,316, 316L
Properties:wedge wire screen
Application:water,oil,liquid filtration,industry filtration

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of stainless steel side hill screen for filtration

Stainless steel side hill screen is easy to penetrate, having good wear-resisting and corrosion resistance. With Trapezoidal cross-section, even gap, stable welding quality, large opening area, long life time, high strength and high load capacity, it can be made into various shapes. The dimensions, wire diameter, slot and frame structure can be customized.

Features of stainless steel side hill wedge wire screen for filtration

• More open area

• Precise openings

• Maximum design flexibility

• Stronger and more durable, economical

• Easier installation and long-term operating etc

Features of stainless steel side hill wedge wire screen for filtration

Energy efficient--operate with no moving parts and with no energy input
Space effficient-- treats up to 122 liters per second per square meter of floor space
Quite operation--no moving parts mean no mechanical or electrial vibrations
Accurate size-- can be used for sizing solid particles down to 0.2mm

Application of stainless steel side hill wedge wire screen for filtration

Sieve bend screens are widely used in mining, coal separation, drilling, fertilizer, food, environmental protection, metallurgy, medicine and other industries.

stainless steel side hill screen for filtratio

Specifications of stainless steel side hill screen for filtration:

Specification (wedge wire):

Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70

Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00

Specification (support rod):

Width(mm): 2.30 3.00 3.30 3.70

Height(mm): 2.70 3.60 4.70 5.60 6.30

Round: From 2.50mm to 6.0mm

Note: other specifications available as per request

Slot Size

0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.

Material:

galvanized low carton (LCG), stainless steel (304,316 etc.)

Length

up to 6 meters.

Width

from 25mm to 1200mm.

Radian



End Connection

Plain beveled ends, flanged or threaded couplings

Packaging and Transportation of stainless steel side hill screen for filtration:

transportation
