stainless steel well point wedge wire screen pipe

More Views

stainless steel well point wedge wire screen pipestainless steel well point wedge wire screen pipestainless steel well point wedge wire screen pipe

stainless steel well point wedge wire screen pipe

Category:Wedge Wire Pipe&Cylinder
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:Wedge wire screen cylinders
Application:deep well , water well , geothermal well , tube well , oil and gas exploration well , irrigation well

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of stainless steel well point wedge wire screen pipe

     We offer a reliable and efficient range of Stainless Steel Wedge Wire Filter Cartridges. Our offered products are extensively demanded by various industries and are manufactured in accordance with the industry set norms and guidelines. Post-production, we test each product on various stages to give our clients

Application for stainless steel well point wedge wire screen pipe

deep well , water well , geothermal well , tube well , oil and gas exploration well , irrigation well , resident and industrial using well

Feature for stainless steel well point wedge wire screen pipe:

1.Up to 60% or more free open entry area
2.Installation possible to depths of 2000 m
3.Smaller diameters can be drilled as gravel packing is not necessarily required
4.The slogs can't be clogged due to wedgeshaped surface wires
5.high quality , lower price , fastest delivery

Characteristics for stainless steel well point wedge wire screen pipe:

1. Custom Designed and Engineered
Each project is specifically designed to ensure complete satisfaction. We provide guidance and support from project concept to completion.
2. Longer lasting.
Wedge Wire Screens, whose manufacturing standards are the most stringent in the industry, are extremely durable and have high resistance to abrasion, corrosion and impact damage.
3. Lower Maintenance.
The rugged construction and high quality of materials make possible a product that lasts longer and requires less maintenance.
4. Less Costly.
Superior operating efficiency, extended service life and reduced main-tenance needs combine to reduce the true cost of Wedge Wire screens to plant operators.

stainless steel well point wedge wire screen pipe

Specifications of stainless steel well point wedge wire screen pipe:

stainless steel well point wedge wire screen pipe

Outside Diameter
Profile
wire
Rod
wire
Rod
quantity
Slot
size
Length
DN
Inch
mm
mm
mm

mm
mm
20
3/4
26.9
1.5*2
2*3
12
0.1~0.25
45~3000
25
1
33.7
1.5*2
2*3
14
0.1~0.25
45~3000
32
1~1/4
42.4
1.5*2
2*3
16
0.1~0.25
45~3000
40
1~1/2
48.3
1.5*2
2*3
16
0.1~0.25
45~3000
50
2
60.3
1.5*2
2*3
18
0.1~0.5
45~3000
65
2~2/2
76.1
1.5*2
2*3
20
0.1~0.5
45~3000
80
3
88.9
1.8*2.5
2*3
24
0.1~0.5
45~3000
100
4
114.3
1.8*2.5
2*3
30
0.5~2
1000~6000
125
5
139.7
2.3*2.7
2*3
36
0.5~2
1000~6000
150
6
168.3
2.3*2.7
3*5
44
0.5~2
1000~6000
200
8
219.1
3.3*4.5
3*4.7
56
0.5~2
1000~6000
250
10
273
3.3*4.5
4*6
66
0.5~2
1000~6000
300
12
323.9
3.3*4.7
4*6
72
0.5~2
1000~6000
350
14
355.6
3.7*5
4*6
80
0.5~2
1000~6000
400
16
406.4
1.5*2
2*3
94
0.1~2
1000~6000
450
18
457
2*3
4*5
112
0.1~2
500~400
500
20
508
2*3
4*5
124
0.1~2
500~400
550
22
559
2*3
4*5
140
0.1~2
500~400
600
24
610
2*3
4*5
156
0.1~2
500~400
Siot:0.1mm~2mm    Tolerance:0.05

Packaging and Transportation of stainless steel well point wedge wire screen pipe:

1.Each product is packed with bubble bag and then few bags to a wooden case (fumigation certificate)
2.We have a very trust forwarding company cooperate for long time and establish a solid partnership,of course,you can also arrange forward to take products from our factory.
