Quality Wedge Wire Screen Manufacturer in China

Rotary drum screen high strength wedge wire screen

More Views

Rotary drum screen high strength wedge wire screenRotary drum screen high strength wedge wire screenRotary drum screen high strength wedge wire screen

Rotary drum screen high strength wedge wire screen

Category:Wedge Wire Pipe&Cylinder
Material:SS 304,316,316L, Stainless steel and carbon steel.
Properties:drum screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of Rotary drum screen high strength wedge wire screen

    Rotary Drum Screens are designed to self clean, with wedge wire tubes supporting and reinforcing the structure. Our Rotary Drum Screens and Trommel Screens are produced to work uninterruptedly. This maintains higher efficiency and productivity whilst at the same time minimising energy consumption. Making the benefits of installing Rotary Drums Screens for your waste water screening needs from Gap Technology a definite must.

Application for Rotary drum screen high strength wedge wire screen :

Rotary Drum Screens are used to mechanically separate liquids from solid particles. Gap Technology offer a wide range of Rotary Drum screens and Rotary Wedge Wire Screens / Trommel Screens for industrial waste water screening applications to our large and varied customer base throughout the United Kingdom and across Europe.

The features for Rotary drum screen high strength wedge wire screen :

1.Drum screen mesh is not easy to jam.
2.Smooth operation, low noise.
3.Simple structure, convenient maintenance.
4.Sieve tube can be closed, airtight dust easily.
5.The whole machine has high reliability, one-time investment is less.
6.Adopts special mesh, high screening efficiency, long service life.

Working Principle for Rotary drum screen high strength wedge wire screen  :

GTS Series wedge wire screen drum screen utilize Mechanical method, compose a screen surface by sieve bar form into pore. Classify by its weight 3 joint shaft inside trommel is higher than surface, to push up big size material so as to increase classify rate. And the inclination will help it advance, enter crusher finally. Size smaller pore will down through the pore and acquire the final product.

Rotary drum screen high strength wedge wire screen

Specifications of Rotary drum screen high strength wedge wire screen:

Rotary drum screen high strength wedge wire screen

Model NO.
Screen Area
(m2)
Sieve hole size (mm)
Seam Size (mm)
Screen Hole (T/D)
Screen Slot (T/D)
Inlet pulp consistency (%)
Motor Power (Kw)
ZNS 0.3
0.3
Φ1.6~Φ3.5
0.1~0.55
50~80
30~50
1~4
22~55
ZNS 0.6
0.6
Φ1.6~Φ3.5
0.1~0.55
90~160
60~100
1~4
30~75
ZNS 0.9
0.9
Φ1.6~Φ3.5
0.1~0.55
135~250
90~150
1~4
37~90
ZNS 1.2
1.2
Φ1.6~Φ3.5
0.1~0.55
180~320
120~190
1~4
45~110
ZNS 1.5
1.5
Φ1.6~Φ3.5
0.1~0.55
200~380
140~230
1~4
55~132
ZNS 2
2
Φ1.6~Φ3.5
0.1~0.55
260~500
220~300
1~4
75~160
ZNS 3
3
Φ1.6~Φ3.5
0.1~0.55
400~700
300~450
1~4
90~220
ZNS 4
4
Φ1.6~Φ3.5
0.1~0.55
500~1000
350~730
1~4
132~280

Packaging and Transportation of Rotary drum screen high strength wedge wire screen:

Rotary drum screen high strength wedge wire screen
