Details of water well filter nozzle

Filter nozzles are used in liquid/solid or gas/solid separation (sand, catalyst, resins, zeolite etc). The design of each nozzle and the exact quantity will be proposed in order to obtain a perfect distribution or collection of flow.
Our filter nozzles are an excellent technical and economical solution in bringing together a fully welded, strong and highly corrosion resistant structure and with a non-plugging surface.

Many processes utilise a nozzle plate :

Catalytic processes
Ion exchange processes
Sand filters
Activated carbon processes
Filter nozzles DESIGN
Nominal diameter is 50 mm.
The height of a nozzle and the internal diameter of the fitting can be approximated using the following graphs.
Slot entrance velocity nominally 0.2m/s (to be optimised dependant upon the filter media)
By optimising the ratio between the head loss of each component (open area and fitting) we can determine the optimum quantity of nozzles to ensure a perfect distribution or collection without channelling, wall effects, or dead zones.

Uses of water well filter nozzle

water softening treatment equipment, replace Polypropylene ( PP ) filter,sand filters, carbon filters, ion exchange systems, carbon absorbers,media retention, backwash retention, resin retention and resin traps.

     water well filter nozzle

Specifications of water well filter nozzle:

Nominal diameter is 50 mm.
The height of a nozzle and the internal diameter of the fitting can be approximated using the following graphs.

Slot entrance velocity nominally 0.2m/s (to be optimised dependant upon the filter media)

filter nozzle

Type in catalogue Slots mm Thread ΦA mm Thread length L1mm Shaft L2mm
A

0.05, 0.1

0.2, 0.3

0.5, 1

11/4"WW   32 25,30,45, +5+5… 80,110,140,200,250,300,350,…
M30×3.5 30 30
G 3/4" 26.5 25,30,45, +5+5… 80,110,140,200,250,300,350,…
1"WW 25.4 20,45, +5+5…
M24 24 25,45, +5+5…
M22×1.5 22 45, +5+5…
G 1/2" 21 20 80, 110, 140, 200,…
M20 20 45, +5+5…
G 3/8" 16.7 20

Packaging and Transportation of water well filter nozzle:


Packaging Details:  packed in a pastic bag,then in a wooden case or as request
Delivery Detail: 20 Days and according to the order quantity
