stainless steel ion excganger v wire filter nozzle
Category: | Filter Nozzle |
---|---|
Material: | stainless steel 304,304L,304HC,316,316L,321,430 or as per your request. |
Properties: | filter nozzle |
Application: | water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant,refining & petrochemical |
if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.
Details of stainless steel ion excganger v wire filter nozzle
stainless steel ion excganger v wire filter nozzles are used in liquid/solid or gas/solid separation. The wedge wire screen design of each nozzle and the exact quantity will be proposed in order to obtain a perfect distribution or collection of flow thus almost eliminating the channeling, wall effects or dead zones.
UBO manufactures stainless steel ion excganger v wire filter nozzles using a variety of materials to ensure long life and reliable performance. The non-plugging, continuous slot design makes UBO nozzles ideal for applications that involve the retention of sand, activated carbon, ion exchange resin and more. They withhold the media while allowing the treated liquid to pass through.
Application of stainless steel ion excganger v wire filter nozzles
The wedge wire screen filter nozzle can be fixed on the filtering equipment for the filteration of water petrol resin and other medium. Also it can be used in the water treatment, water softhening, conversion of sea water into fresh water, the filter of food chemistry.
Advantages of stainless steel ion excganger v wire filter nozzles
Excellent roundness
Very good slot width precision
High mechanical load capacity
No form closure connection that would allow vibration of the profiled bars V-shaped wire around the twin tube water cap for metallurgical industry
Automated welding process for high-precision manufacturing
Perfectly adjusted screen basket profiles
Available for all screens
Surface finishing as require
Specifications of stainless steel ion excganger v wire filter nozzle:
|
|||||||
Slot (mm) |
Dimension |
Flow Rating (M3/H) |
|||||
D(mm) |
H(MM) |
L(MM) |
Thread |
Fittings |
|||
UBO-0.5 |
0.25 |
45 |
45 |
90/request |
M,NPT, G, PT(BSPT),Z,BSP, request |
SS Gasket, Rubber gasket, Nut, request |
0.5 |
UBO-1.0 |
0.25 |
53 |
45 |
90/request |
1.0 |
||
UBO-1.5 |
0.25 |
57 |
45 |
90/request |
1.5 |
||
UBO-2.0 |
0.25 |
57 |
55 |
100/request |
2.0 |
||
UBO-2.5 |
0.25 |
70 |
55 |
100/request |
2.5 |
||
UBO-3.0 |
0.25 |
70 |
70 |
120/request |
3.0 |
||
Note |
* All the above size are the normal size. Customized size is possible. * UBO could help to design according to the application and requirement. * The nozzles customized range as below: 1. Slot range: 0.05-2mm 2. Dimension: Diameter, Screen Height, Length could produce according to actual requirement and application 3. Thread according to requirement |
Packaging and Transportation of stainless steel ion excganger v wire filter nozzle:
