SS 304 wedge wire screen plate for false bottom

More Views

SS 304 wedge wire screen plate for false bottomSS 304 wedge wire screen plate for false bottomSS 304 wedge wire screen plate for false bottom

SS 304 wedge wire screen plate for false bottom

Category:Wedge Wire Screen Panel
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:lauter tun screen
Application:water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant,refining & petrochemical

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:yolanda

Detailed description of the SS 304 wedge wire screen plate for false bottom

SS 304 wedge wire screen plate for false bottom is a screen for your mash tun that will keep your grains in place and allow the liquid to flow throughout the sparging or recirculation process without clogging your system. A UBO false bottom screen is a great, more affordable alternative to a false bottom that once fitted, will allow the liquid to flow while keeping the grain sediment out, or can be used with your boil kettle to filter out your hops, keeping the residue out of your fermenter.

SS 304 <a href='http://www.ubowedgewire.com/' target='_blank'>wedge wire screen</a> plate for false bottom

SS 304 <a href='http://www.ubowedgewire.com/' target='_blank'>wedge wire screen</a> plate for false bottom

SS 304 <a href='http://www.ubowedgewire.com/' target='_blank'>wedge wire screen</a> plate for false bottom

Feature of SS 304 wedge wire screen plate for false bottom

Wedge Wire Lauter Tun Screen lauter tun lauter arctic cold brew is easy to penetrate, having good wear-resisting and corrosion resistance. With Trapezoidal cross-section, even gap, stable welding quality, large opening area, long life time, high strength and high load capacity, it can be made into various shapes. The dimensions, wire diameter, slot and frame structure can be customized.

Application of SS 304 wedge wire screen plate for false bottom

1. Mineral processing;
2. Hatchery screens ;
3. Food processing ;
4. Surface water intake screens ;
5. Fish diversion screen panels ;
6. Vibrating or static screen decking ;
7. Flooring for malt kiln, germination, and grain drying.

SS 304 <a href='http://www.ubowedgewire.com/' target='_blank'>wedge wire screen</a> plate for false bottom

SS 304 <a href='http://www.ubowedgewire.com/' target='_blank'>wedge wire screen</a> plate for false bottom

The specifications of the SS 304 wedge wire screen plate for false bottom:

SS 304 <a href='http://www.ubowedgewire.com/' target='_blank'>wedge wire screen</a> plate for false bottom

Normal Name

Lauter Tun Screen, Mash Tun Screen, False Bottom Screen, Etc.

Diameter Range

(MM)

200mm To 2500mm. Diameter Customized

Normal Diameter

(MM)

29”, 30”, 35”, 37”, 40”, 45”, 47”, 59”, 63”, 74”, Etc

Normal Slot

(MM)

0.7mm, 0.75mm, 0.8mm, 1.0mm, customized

Normal Thickness (MM)

8.5mm, 20mm. 25mm, 30mm, 40mm, 50mm, Customized.



Sections & shape

1 Cycle, 2 PCS, 3 PCS, 4 PCS, 6 PCS, 8 PCS. Customized

Wedge wire

(MM)

2x4MM Wedge Wire, 3x5MM Wedge Wire

Support Rod

 (MM)

3x5MM V shaped Support Rod, 3x5mm Square Support Rod

Strengthen Rod

(MM)

Thickness and Height according to the diameter and screen thickness

Note

Usually customized.

The Packaging and Transportation of the SS 304 wedge wire screen plate for false bottom:

transportation of SS 304 <a href='http://www.ubowedgewire.com/' target='_blank'>wedge wire screen</a> plate for false bottom
