Details of Wedge Wire cylinder mesh Screen and continuous slot screen manufacturer

Wedge Wire screen pipe consists of an outer jacket that is fabricated on special wrapping machines that resemble a lathe. The shaped wire is simultaneously wrapped and welded to longitudinal rods to form a single helical slot with any desired width. The jacket is subsequently placed over and welded at each end to a supporting pipe base (containing drilled holes) to provide structural support

Wedge Wire cylinder mesh Screen and continuous slot screen manufacturer

Applications for wedge wire cylinder mesh screen and continuous slot screen:

Wedge Wire wedge wire water well screen filter are mainly used for the water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant ,sewage treatment and other industries,water,oil or gas filter and other filtration equipment.

Features for wedge wire cylinder mesh screen and continuous slot screen:

1) It has high mechanical strength, can bear large pressure drop.

2) The type slot can improve backflushing and regeneration performance.

3) Resistance to pressure, temperature, aging, corrosion, uedes in kinds of fluid.

4) Equal slots for filtering, can form equally distributed filter cake, easy to clean for reuse.

Filtrations Direction for Wedge Wire cylinder mesh Screen and continuous slot screen:

The direction of the flow is determined by the position of the surface profiles in relation to the support profiles. Wedge wire screens are either flow-out-to-in (FOTI) or flow-in-to-out (FITO)

Wedge Wire cylinder mesh Screen and continuous slot screen manufacturer


Wedge Wire cylinder mesh Screen and continuous slot screen manufacturer

Specifications of Wedge Wire cylinder mesh Screen and continuous slot screen manufacturer:

Wedge Wire cylinder mesh Screen and continuous slot screen manufacturer

Outside Diameter
Profile wire
Rod wire
Rod quantity
Slot size
Length
DN
Inch
mm
mm
mm

mm
mm
20
3/4
26.9
1.5*2
2*3
12
0.1~0.25

45~3000

25
1
33.7
1.5*2
2*3
14
0.1~0.25

45~3000

32
1-1/4
42.4
1.5*2
2*3
16
0.1~0.25

45~3000

40
1-1/2
48.3
1.5*2
2*3
16
0.1~0.25

45~3000

50
2
60.3
1.5*2
2*3
18
0.1~0.5

45~3000

65
2-1/23
76.1
1.5*2
2*3
20
0.1~0.5

45~3000

80
3
88.9
1.8*2.5
2*3
24
0.1~0.5

1000~6000

100
4
114.3
1.8*2.5
2*3
30
0.5~2

1000~6000

125
5
139.7
2.3*2.7
2*3
36
0.5~2

1000~6000

150
6
168.3
2.3*2.7
3*5
44
0.5~2

1000~6000

200
8
219.1
3.3*3.5
3*4.7
56
0.5~2

1000~6000

250
10
273
3.3*3.5
4*6
66
0.5~2

1000~6000

300
12
323.9
3.3*4.7
4*6
72
0.5~2

1000~6000

350
14
355.6
3.7*5
4*6
80
0.5~2

1000~6000

400
16
406.4
1.5*2
2*3
94
0.1*2

1000~6000

450
18
457
2*3
4*5
112
0.1*2

500~400

500
20
508
2*3
4*5
124
0.1*2

500~400

550
22
559
2*3
4*5
140
0.1*2

500~400

600
24
610
2*3
4*5
156
0.1*2

500~400

Siot:0.1mm~2mm    Tolerance:0.05
