Standard wound stainless steel wedge v wire screen filter tube

More Views

Standard wound stainless steel wedge v wire screen filter tubeStandard wound stainless steel wedge v wire screen filter tubeStandard wound stainless steel wedge v wire screen filter tube

Standard wound stainless steel wedge v wire screen filter tube

Category:Wedge Wire Pipe&Cylinder
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen cylinder
Application:water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant,refining & petrochemical

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:yolanda

Detailed description of the Standard wound stainless steel wedge v wire screen filter tube

   Standard wound stainless steel wedge v wire screen filter tube, also called round slot tube. It is made of stainless steel wire, which is the most popular type because of outstanding chemical stability and corrosion resistance. The stainless steel cylindrical wedge wire screensis composed of working profile and support profile. It is produced on an automotive machine. The support profiles is placed on the suit position of the machine, during the surface profiles are spirally wounding, the support profiles are welded onto the surface profiles.

Standard wound stainless steel wedge v wire screen filter tube

Features of Standard wound stainless steel wedge v wire screen filter tube

1. Screens with high open area are more suitable for the construction of high-quality water wells, oil wells and gas wells.
2. Low cost operation Screens with high open area shall favor groundwater infiltration. Abundant water shall reduce the water levels down, thus to save energy consumption.
3. Reduce the abrasion of the pump
Under the same condition, high open area can make the speed of groundwaters entering into the screen much slower than any other filtration apparatus, which will avoid sands entering into.

Application of Standard wound stainless steel wedge v wire screen filter tube

Application in deep well pump to dive the water pump, in the water-treating equipment, the environmental protection, the sea water transforms into the industrial water and life use water desalination treatment, running water treatment, water softening treatment; the petroleum industry, the petroleum product terminal filters; and the chemical acid, the alkali liquid filters, the ethyl alcohol and the organic solution recycling filters.

Standard wound stainless steel wedge v wire screen filter tube

Standard wound stainless steel wedge v wire screen filter tube

Standard wound stainless steel wedge v wire screen filter tube

The specifications of the Standard wound stainless steel wedge v wire screen filter tube:



                            Standard wound stainless steel wedge v wire screen filter tube

Wire Size

Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70
Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30

Support Rods

Width(mm): 2.30 3.00 3.30 3.70
Height(mm): 2.70 3.60 4.70 5.60 6.30

Note: other wires and rods available upon request

Slot size

0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.

Material:

Low carton, low carton galvanized steel (LCG), stainless steel (304,316 etc.)

Length

Lengths up to 6 meters.

Diameter

ranging from 25mm to 800mm.

End connection

Plain beveled ends for butt welding or threaded

The Packaging and Transportation of the Standard wound stainless steel wedge v wire screen filter tube:

Standard wound stainless steel wedge v wire screen filter tube
